Maxima is a robust, versatile large-panel 80kN/m² wall formwork system, with column and stripping corner add-ons providing unrivaled flexibility.
Got a question? Get in touch to speak to one of our specialists
Faster
When stacking panels vertically, Maxima's panel alignment clamp dramatically reduces the amount of accessories required to stiffen the horizontal joint for crane handling purposes.
Safer
The Maxima crane hook attaches simply to panel edge members for safe and efficient crane handling.
Easier
With a choice of 7 standard panel widths in 3 different heights plus fixed and hinged corner units virtually any wall formwork application can be accommodated with standard components.
Key features
-
Range of panel sizes
Supplied in 7 different widths and 3 different heights for unrivalled forming flexibility on-site. -
Galvanised panel frames
All frames are hot dipped galvanised to ensure long life use of the panel without rusting. -
Unrivaled concrete pressures
Maxima columns allow unrivalled concrete pressure of 166kN/m². A hoop ladder system is also available to provide safe access and options are available to line forms with plywood to improve surface finish. -
No need for through ties
Maxima columns up to 750mm x 750mm and 3300mm high can be constructed using single panels, removing the requirement for through ties. Pour heights above 3300mm are easily achieved by joining panels together with clamps. -
Choice of pullbacks
Choice of ratchet turn-buckle or hydraulic pull back systems. -
Compatible with all panels including Minima
300 x 300mm corner interchanges with existing schemes.
